ULTRA-LOW NOx gas burner AVP

Characteristics:

AVP burners are the most modern types of ULTRA – LOW NOX automatic gas burners, which are designed for burning natural gas. Their design and operation meet the requirements of European Standards. Their operation is fully automatic and does not require permanent operation. Continuous heat output control and low excess combustion air ensure high efficiency of operation.

The system can be supplemented with continuous analysis of E.G.A. flue gases and, based on its results, can be automatically tuned to combustion, which allows to observe the set combustion parameters even with temperature or pressure changes (change in air or gas temperature, change in pressure or gas composition, ect.).

In addition to the usual functions, the standard automatic design allows:

• displaying the cause of the fault condition, which allows fast and qualified intervention by operators or service personnel
• displaying the current level of the flame sensor
• closing of the air inlet during each operating shutdown, thus reducing the chimney loss due to the flow of cold air
• cascading boiler shifting
• keeping the unit in standby mode
• information about the operating states of the burner
• double VPS (valve proof system)
• information about the position of individual servomotors in degrees
• information about immediate and total gas consumption in m3
• information about the immediate operating power of the burner in %
• in the case of the use of a continuous E.G.A. flue gas analyser, information about O2, CO2, CO and NOx in ppm, flue gas temperature in °C, and combustion efficiency

 Main technical parameters:
